| Name | Value |
| Form Factor | Media Converter |
| Data Rate | 1000M |
| Distance | 20km |
| Wavelength | 1310nm |
| LD | FP |
| PD | PIN |
| Connector | SC |
| DDM | RJ45 |
RM-2100 series Gigabit Ethernet media converter adopts switching technology to fulfill media conversion. It complies with IEEE802.3z and IEEE802.3ab standards, and supports two types of media network connections: 1000Base-T and 1000Base-SX/LX.
It inter-converts electrical signals of 1000Base-T twisted pairs with optical signals of 1000Base-SX, extending the transmission distance of a network from 100m via copper cables to 80km via fiber optical cables.
It supports transmission in multi-mode dual fiber, single-mode dual fiber, single-mode single fiber.
| Parameter | Specifications |
| Access mode | 1000Mbps Gigabit Ethernet |
| Standard | IEEE802.3ab 1000Base-T, IEEE802.3z 1000Base-SX/LX Gigabit thernet,IEEE802.1qVLAN,IEEE802.1p QoS,IEEE802.1d Spanning Tree |
| Wavelength | Mulitmode:850/1310nm; Single-mode:1310/1550nm (Option) |
| Distance | Category-5 twisted pair: 100m |
| Fiber：multi-mode 50/125，62.5/125μm（the max distance up to(220m or 550m） | |
| Fiber：Single -mode 8/125，8.7/125，9/125，10/125μm（the max distance up to 20 -80km） | |
| Port | One RJ45 port: |
| For connecting STP/UTP category-5 twisted pairs | |
| One optical port: | |
| Multi-mode, dual fiber:SC(50, 62.5/125μm) | |
| Single mode, dual fiber:SC or FC (9/125μm) | |
| Single mode Single fiber: SC or FC (9/125μm) | |
| Conversion means | Media conversion |
| MAC address table | 1K |
| Buffer space | 512kbit |
| Flow control | Full duplex: flow control; |
| Half duplex: back pressure | |
| Delay | Store-and-forward: 9.6μs; cut-through: 0.9μs |
| BER | <19-9 |
| MTBF | 100,000 hours |
| LED indicator | PWR (power supply), FX LINK (optical link action), TP LINK1000 (twisted pair link1000M), TP LINK100 (twisted pair link 100M), TP ACT (twisted pair packet forwarding) |
| Power supply | DC5V 1A (external), AC220 0.5A/DC-48 (internal) |
| Power consumption | 5W |
| Operating temperature | -10~55ºC |
| Operating humidity | 5%~90% |
| Maintaining temperature | -40~70ºC |
| Maintaining humidity | 5% ~ 90% non-condensing |
| Dimensions | External power supply: 26mmx 71mm x 94mm |
| Internal power supply: 40mm x 110mm x 140m |
| Model | wavelength | Fiber | TX port | Fiber Mode | TX power (dBm) | RX Sen. | Distance |
| (dBm) | |||||||
| RM-2100-SR | 850nm | SC/ST | RJ-45 | MM,Duplex | -17~-12 | ≤-20.0 | 550m |
| RM-2100-L2 | 1310nm | SC/FC | RJ-45 | SM, Duplex | -3~-8 | ≤-23.0 | 20km |
| RM-2100-L4 | 1310nm | SC/FC | RJ-45 | SM, Duplex | -3~-0 | ≤-25.0 | 40km |
| RM-2100-L6 | 1310nm | SC/FC | RJ-45 | SM, Duplex | >1 | ≤-27.0 | 80km |
| RM-2101-L2A | T1310/R1550 | SC | RJ-45 | SM,BI-DI | -8~-3 | ≤-23.0 | 20km |
| RM-2101-L2B | T1310/R1550 | SC | RJ-45 | SM,BI-DI | -8~-3 | ≤-23.0 | 20km |
| RM-2101-L4A | T1310/R1550 | SC | RJ-45 | SM,BI-DI | -3~0 | ≤-23.0 | 40km |
| RM-2101-L4B | T1550/R1310 | SC | RJ-45 | SM,BI-DI | -3~0 | ≤-23.0 | 40km |
| RM-2101-L6A | T1490/R1550 | SC | RJ-45 | SM,BI-DI | -3~0 | ≤-23.0 | 60km |
| RM-2101-L6A | T1550/R1490 | SC | RJ-45 | SM,BI-DI | -3~0 | ≤-23.0 | 60km |
