• Wavelength selectable to ITU-T standards covering CWDM grid wavelengths
• XFP MSA Compliant
• data rate from 9.95 Gbps to 11.3Gbps
• No Reference Clock required
• Cold EML transmitter and PIN receiver
• link length up to 40km (800ps/nm)
• Low Power Dissipation 3.5W Maximum
• -5ºC to 70ºC Operating Case Temperature
• Diagnostic Performance Monitoring of module temperature, supply Voltages, laser bias current, transmit optical power, receive optical power
• RoHS compliant and lead free

• SONET OC-192&SDH STM 64
• 40 km 10G Fiber Channel
• CWDM Networks

Reach Optics' CWDM XFP Transceiver exhibits excellent wavelength stability, cost effective module. It is designed for 10G CWDM SDH, 10GBASE-ER/EW and 10G Fiber- Channel applications.

The transceiver consists of two sections: The transmitter section incorporates a colded EML laser. And the receiver section consists of a PIN photodiode integrated with a TIA. All modules satisfy class I laser safety requirements.

Reach Optics' CWDM XFP transceiver provides an enhanced monitoring interface, which allows real-time access to device operating parameters such as transceiver temperature, laser bias current, transmitted optical power, received optical power and transceiver supply voltage.
