• Supports 9.95Gb/s to 11.1Gb/s bit rates
• Hot-pluggable XFP footprint
• Maximum link length of 10km with SMF
• 1270/1330nm DFB laser Transmitter and 1330/1270nm Receiver
• XFP MSA package with LC connector
• No reference clock required
• Loop Back Support.
• +3.3V，+1.8V power supply
• Power dissipation <2W
• Compatible with RoHS
• Built-in digital diagnostic functions
• Temperature range 0°C to 70°C

• 10GBASE-BX 10G Ethernet

Reach Optics' RXFB-XXXX96-10D is compliant with the IEEE803.3ae 10Gbase-Bx. and transmission distance up to 10km on SMF.

The transceiver module comprises a transmitter with a 1270/1330nm DFB laser transmitter, an integrated 1330/1270nm detector preamplifier(IDP) mounted in an optical header and a limiting post-amplifier IC. Transmitter and receiver are separate within a wide temperature range of  0℃ to +70℃  and offers optimum heat dissipation and excellent electromagnetic shielding thus enabling high port densities for 10 GbE systems.
