• Supports 9.95Gbps to 10.5Gbps bit rates
• Maximum link length of 300m (50um,MMF,2000MHz.Km)
• 850nm VCSEL laser and PIN receiver
• Low power consumption <1.5W
• +3.3V +1.8Vpower supply
• XFP MSA package with duplex LC connector
• XFI electrical interface
• No reference clock required
• Compatible with RoHS
• Excelllent EMI performance
• Built-in digital diagnostic functions
• Temperature range: 0℃ to +70℃
• High reliability

• 10GBASE-SR/SW 10G Ethernet
• 1200-Mx-SN-I 10G Fibre Channel
• Other optical links

Reach Optics' RXF-8596-S3D is compliant with the 10G Small Form-Factor Pluggable (XFP) Multi-Source Agreement (MSA), supporting data-rate of 10.3125Gbps(10GBASE-LR) or 9.953Gbps 10GBASE-LW), and transmission distance up to 300m on 50μm MMF (2000MHz.km).

The transceiver module comprises a transmitter with 850nm a vertical cavity surface emitting (VCSEL) laser and a receiver with a PIN photodiode. Transmitter and receiver are separate within a wide temperature range of 0℃ to +70℃ and offers optimum heat dissipation and excellent electromagnetic shielding thus enabling high port densities for 10 GbE systems.
