| Name | Value |
| Form Factor | SFP+ CWDM |
| Data Rate | 10G |
| Distance | 100km |
| Wavelength | 1470nm~1610nm |
| LD | EML |
| PD | APD |
| Connector | LC |
| DDM | Y |
| Part Number | Data Rate (Gb/s) | Wavelength(nm) | Transmission Distance(km) | Temperature (oC) (Operating Case) |
| RSPC-XX96-100CD | 10.3125 | Refer to wavelength selection | 100km SMF | 0~70 commercial |
| RSPC-XX96-100ED | 10.3125 | Refer to wavelength selection | 100km SMF | -10~80 Extended |
| RSPC-XX96-100ID | 10.3125 | Refer to wavelength selection | 100km SMF | -40~85 Industrial |
| Wavelength | xx | Clasp Color Code | Wavelength | xx | Clasp Color Code |
| 1470 nm | 47 | Gray | 1550 nm | 55 | Yellow |
| 1490 nm | 49 | Purple | 1570 nm | 57 | Orange |
| 1510 nm | 51 | Blue | 1590 nm | 59 | Red |
| 1530 nm | 53 | Green | 1610 nm | 61 | Brown |
| Part Number | Product Description |
| RSPC-4796-100CD | 10Gbps, 1470nm SFP+ CWDM 100km, -5ºC ~ +70ºC |
| RSPC-4996-100CD | 10Gbps, 1490nm SFP+ CWDM 100km, -5ºC ~ +70ºC |
| RSPC-5196-100CD | 10Gbps, 1510nm SFP+ CWDM 100km, -5ºC ~ +70ºC |
| RSPC-5396-100CD | 10Gbps, 1530nm SFP+ CWDM 100km, -5ºC ~ +70ºC |
| RSPC-5596-100CD | 10Gbps, 1550nm SFP+ CWDM 100km, -5ºC ~ +70ºC |
| RSPC-5796-100CD | 10Gbps, 1570nm SFP+ CWDM 100km, -5ºC ~ +70ºC |
| RSPC-5996-100CD | 10Gbps, 1590nm SFP+ CWDM 100km, -5ºC ~ +70ºC |
| RSPC-6196-100CD | 10Gbps, 1610nm SFP+ CWDM 100km, -5ºC ~ +70ºC |
