155M BIDI SFP 120km 1490nm TX / 1550nm RX

155M BIDI SFP 120km 1490nm TX / 1550nm RX
Item : RSB-4501x-120C(D)
Name Value

Form Factor SFP BI-DI
Data Rate 155M
Distance 120km
Wavelength T1490/R1550
LD DFB
PD PIN
Connector LC/SC
DDM Y/N
BIDI 1490/1550NM 120km Fiber SFP Factory Price

1. 155M WDM SFP DDM
2. 155M BIDI SFP Transceiver
3. 155M,Tx:1490nm/Rx:1550nm, LC, 120km
4. FCC CE ROHS
5. OEM ODM

Product Description

RSB-4501x-120C(D)

155Mbps SFP Bi-Directional Transceiver, 120km Reach

1490nm TX / 1550 nm RX

Features

Up to 155Mbps data-rate
1490nm DFB laser and PIN photodetector for 120km transmission
Compliant with SFP MSA and SFF-8472 with duplex LC receptacle
Digital Diagnostic Monitoring:
Internal Calibration or External Calibration
Compatible with RoHS
+3.3V single power supply
Operating case temperature:
Standard : 0 to +70°C

Applications

SDH STM-1, S-1.1,L-1.1, L-1.2
SONET OC-3 IR1,LR1,LR2
Other optical links

Description

The SFP-BIDI transceivers are high performance, cost effective modules supporting data-rate of 155Mbps and 120km transmission distance with SMF.

The transceiver consists of three sections: a DFB laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements.

The transceivers are compatible with SFP Multi-Source Agreement (MSA) and SFF-8472. For further information, please refer to SFP MSA.

Ordering information

Part Number	Product Description
RSB-4501S-120C	1490nm, 155Mbps, SC, 120km, 0°C~+70°C
RSB-4501S-120CD	1490nm, 155Mbps, SC, 120km, 0°C~+70°C, With Digital Diagnostic Monitoring
RSB-4501L-120C	1490nm, 155Mbps, LC, 120km, 0°C~+70°C
RSB-4501L-120CD	1490nm, 155Mbps, LC, 120km, 0°C~+70°C, With Digital Diagnostic Monitoring

Name	Value
Form Factor	SFP BI-DI
Data Rate	155M
Distance	120km
Wavelength	T1490/R1550
LD	DFB
PD	PIN
Connector	LC/SC
DDM	Y/N
